Product model: TYD-918 Shell material: metal shell Appearance color: black Imaging device: 1/3 SONY CCD Signal system: PAL/NTSC Effective pixels: 752 (horizontal) × 582 (vertical) / 768 (horizontal) × 494 (vertical)
| 1 | Product number | TYD-918 |
| 2 | shell material | metal shell |
| 3 | Exterior color | black |
| 4 | Imaging device | 1/3 SONY CCD |
| 5 | Signal System | PAL/NTSC |
| 6 | Effective Pixels | 752 (horizontal) × 582 (vertical) / 768 (horizontal) × 494 (vertical) |
| 7 | Synchronization system | Internal synchronization |
| 8 | Horizontal resolution | 800TV lines |
| 9 | Minimum illumination | 0 LUX{infrared start} |
| 10 | Video output | 1.0vp-p, 75Ω |
| 11 | Gamma Coefficient | 0.45 |
| 12 | Signal-to-noise ratio | Greater than 48dB |
| 13 | White balance | Auto |
| 14 | Electronic shutter | 1/60-1/100000 (seconds) |
| 15 | BLC | Auto |
| 16 | Current | 210mA±10% (infrared start), 70mA±10% (infrared not start) |
| 17 | Voltage | DC 12V±10% |
| 18 | Operating temperature | －20°C~70°C |
| 19 | Relative ambient temperature | Humidity is between 30% and 85% |
| 20 | Camera angle | 3.6/2.8可选 90°/120° |
| 21 | Use environment | outdoor |
| 22 | Protection level | IP67 |
| 23 | Connection connector | Standard 4-core aviation head (customizable) |
| 24 | microphone | 无 |
| 25 | Camera weight | 220g |
